Bộ lưu điện APC SMT3000RMI2UC

Bộ lưu điện APC SMT3000RMI2UC

Output

Max Configurable Power (Watts):2.7kWatts / 3.0kVA

Output Voltage Note:Configurable for 220 : 230 or 240 nominal output voltage

Output Voltage Distortion:Less than 5%

Output Frequency (sync to mains):50/60Hz +/- 3 Hz

Other Output Voltages:220, 240

Topology:Line Interactive

Waveform type:Sine wave

Transfer Time:6ms typical : 10ms maximum

Input

Input frequency:50/60 Hz +/- 3 Hz (auto sensing)

Input voltage range for main operations:160 - 286V

Input voltage adjustable range for mains operation:151 - 302V

Number of Power Cords:1

Other Input Voltages:220, 240

Batteries & Runtime

Battery type:Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof

Typical recharge time:3hour(s)

Replacement Battery:RBC43

Expected Battery Life (years):3 - 5

RBC Quantity:1

Battery Charge Power (Watts):182Watts

Battery Volt-Amp-Hour Capacity:547

Runtime

View Runtime Graph

View Runtime Chart

Efficiency

View Efficiency Graph

Communications & Management

Interface Port(s):RJ-45 Serial, SmartSlot, USB

Control panelMulti-function LCD status and control console

Audible Alarm:Alarm when on battery : distinctive low battery alarm : configurable delays

Available SmartSlot™ Interface Quantity:1

Surge Protection and Filtering:Surge energy rating

320Joules

Physical

Maximum Height:86MM, 8.6CM

Maximum Width:432MM, 43.2CM

Maximum Depth:683MM, 68.3CM

Net Weight:44.28KG

Shipping weight:51.7KG

Shipping Height:254MM, 25.4CM

Shipping Width:600MM, 60.0CM

Shipping Depth:980MM, 98.0CM

Units per Pallet:8.0

Environmental

Operating Temperature:0 - 40 °C

Operating Relative Humidity:0 - 95 %

Operating Elevation:0-3000meters

Storage Temperature:-15 - 45 °C

Storage Relative Humidity:0 - 95 %

Storage Elevation:0-15000meters

Audible noise at 1 meter from surface of unit:55.0dBA

Online thermal dissipation:348.0BTU/hr

Conformance

Approvals:CE, EAC, EN 60950, EN/IEC 62040-1, EN/IEC 62040-2, GS Mark, IRAM, RCM, VDE, WEEE

Standard warranty:3 years repair or replace (excluding battery) and 2 year for battery

Sustainable Offer Status

RoHS:Compliant

REACH

REACH: Contains SVHCs
